Tonghao CPD12 Electric Forklift

Tonghao CPD12 forklift has outstanding performance and design. Its main mast uses 12# steel channel, is equipped with an integrated high-quality forged fork and has a forward and backward tilt function, which not only ensures high strength and stability, but also helps the operator to accurately stack goods.     The vehicle reserves space for battery expansion, which can be adjusted according to the workload to meet the needs of long-term operations. At the same time, the high-strength acrylic protective plate at the mast,   the protective arms on both sides of the driver’s seat, the emergency reverse switch on the control handle, and the lifting electric limit and high cargo speed limit devices, etc., all build a comprehensive safety protection system, and the pedal is equipped with a shock absorber to bring a comfortable operating experience.   In terms of configuration parameters, the CPD12 forklift has a rated load capacity of 1200kg and a load center distance of 400mm. Its full-load travel speed is 5.2km/h, empty-load is 5.5km/h, full-load lifting speed is 95mm/s, empty-load is 130mm/s, full-load lowering speed is 105mm/s, empty-load is 100mm/s.   In addition, different brands of CPD12 forklifts have their own characteristics in details. Some models have variable wheelbase design, EPS electronic steering, cornering deceleration and other functions, which can operate flexibly in narrow spaces and are suitable for warehousing, logistics, manufacturing and other scenarios, effectively improving the efficiency and safety of material handling.     Technical Parameter 1.1 Model CPD12 1.2 Power type Electric 1.3 Operation type Saddle-type 1.4 Load 0 kg 1200 1.5 Load center distance 丁 mm 500 1.6 Front overhang X mm 290 1.7 Wheelbase y mm 1400 2.1 Weight (including battery) kg 1700 3.1 Tire type, drive wheel/steering wheel Solid tire 3.2 Driving wheel size (diameter x width) mm 500-8 3.3 Steering wheel size (diameter x width) mm 500-8 3.4 Driving wheel, number of steering wheels (x=driving wheel) mm 2X/2 3.5 Driving wheel track b10 mm 950 3.6 Steering wheel track b11 mm 920 4.1 Mast and fork tilt angle α/β(°) 1212122025年5月9日 4.2 Mast height after lowering h1 mm 2150 4.3 Maximum lifting height of standard mast h3 mm 3000 4.4 Mast height when lifting to the highest position h4 mm 4000 4.5 Head guard (cockpit) height h6 mm 2050 4.6 Seat surface Height h7 mm 1030 4.7 Height of the center of the traction pin h10 mm 460 4.8 Length of the vehicle I1 mm 3170 4.9 Length to the vertical plane of the fork 12 mm 2060 4.1 Overall width b1/ b2 mm 1100 4.11 Fork size s/e/1 mm 40X80X1070 4.12 Fork frame outer width b3 mm 1040 4.13 Ground clearance of the lower end of the fully loaded mast m1 mm 110 4.14 Minimum ground clearance of the vehicle body m2 mm 100 4.15 Aisle width of the pallet is 1200 wide x 1000 long Ast mm 3280 4.16 Aisle width of the pallet is 800 wide x 1200 long Ast mm 3480 4.17 Turning radius Wa mm 1780 5.1 Travel speed, fully loaded/unloaded km/h 1212122025年10月12日 5.2 Lifting speed, fully loaded/unloaded m/s 0.24/0.3 5.3 Descending speed, fully loaded/unloaded m/ s 0.4/0.36 5.4 Maximum climbing grade, fully loaded/unloaded % 14/15 5.5 Service brake type Hydraulic mechanical 5.6 Parking brake type Mechanical 6.1 Drive motor rated power S260 minutes kw 4 6.2 Lifting motor rated power S315% kw 4 6.3 Battery voltage/nominal capacity K5 ah 6.4 Drive control type AC
