Tonghao CPD100 Electric Forklift

Tonghao CPD100 forklift is a heavy-duty electric counterbalanced forklift with a rated load of up to 10,000kg, designed for large and heavy material handling. Its sturdy frame made of high-strength alloy steel and reinforced gantry structure effectively improve the stability and carrying capacity of the vehicle, and can maintain stable operation under heavy loads;      with large-size wide-base solid tires, it enhances grip and wear resistance and adapts to a variety of complex ground environments. The vehicle is equipped with an efficient and environmentally friendly electric drive system to achieve zero emissions and low noise operation, which meets the needs of green operations; the advanced battery management system combined with fast charging technology greatly improves endurance and ensures long-term continuous operation.     In terms of configuration and operating experience, the CPD100 forklift also performs well. The cab follows the ergonomic design, equipped with a suspended shock-absorbing seat, a multi-functional integrated operating handle, and a reasonable layout of the operating interface, which is convenient for the driver to operate efficiently; the spacious field of view design and the panoramic reversing image system effectively improve the safety of the operation. The vehicle’s driving, lifting and lowering speeds can be intelligently adjusted according to different working conditions, significantly improving the operating efficiency.     The maintenance-free AC drive system and fully sealed maintenance-free battery greatly reduce the cost and frequency of subsequent maintenance. In addition, intelligent safety devices such as anti-collision warning and automatic emergency braking can be optionally installed to protect the safety of operations in all directions. It is widely used in ports, steel, mines, large-scale warehousing and logistics and other industry scenarios with strict requirements for heavy-load handling.   CPD100 heavy-duty electric counterbalanced forklift, rated at 10,000kg, excels in large-scale heavy material handling. Its high-strength alloy steel frame and reinforced gantry ensure stability under heavy loads, while wide-base solid tires handle tough terrains. The eco-friendly electric drive with advanced battery management and fast charging offers extended operation. Ergonomically designed with intuitive controls, adjustable speeds, and low-maintenance components, it boosts efficiency. Optional intelligent safety features safeguard operations, making it ideal for demanding heavy-load scenarios in ports, steel, mining, and logistics.       Technical Parameter 1.1 Model CPD100 1.2 Power type Electric 1.3 Operation type Saddle-type 1.4 Load Q kg 10000 1.5 Load center distance C mm 600 1.6 Front overhang X mm 660 1.7 Wheelbase y mm 2550 2.1 Weight (including battery) kg 13200 3.1 Tire type, drive wheel/steering wheel Pneumatic tire/solid tire 3.2 Drive wheel size (diameter x width) mm 8.25-15 3.3 Steering wheel size (diameter x width) mm 250-15 3.4 Drive wheel, number of steering wheels (x = drive wheel) mm 4X2 3.5 Drive wheel track b 10 mm 1480 3.6 Steering wheel track b 11 mm 1500 4.1 Mast and fork tilt angle α/ β (°) 5/9 4.2 Mast height after lowering h1 mm 2820 4.3 Maximum lifting height of standard mast h3 mm 3000 4.4 Mast height when lifted to the highest level h4 mm 4300 4.5 Head guard (cockpit) height h6 mm 2450 4.6 Seat surface height h7 mm 1350 4.7 Height of towing pin center h 10 mm 750 4.8 Vehicle length l1 mm 5210 4.9 Length to vertical surface of fork l2 mm 3905 4.10 Overall width b 1/ b2 mm 2000 4.11 Fork size s/ e/ l mm 85X175X1220 4.12 Fork frame outer width b3 mm 1850 4.13 Ground clearance of lower end of fully loaded mast m1 mm 130 4.14 Minimum ground clearance of vehicle body m2 mm 220 4.15 Aisle width of pallet is 1200 wide x 1000 long Ast mm 5350 4.16 Aisle width of pallet is 800 wide x 1200 long Ast mm 5550 4.17 Turning radius Wa mm 3460 5.1 Travel speed, fully loaded/unloaded km/ h 13/15 5.2 Lifting speed, fully loaded/unloaded m/ s 0.28/0.34 5.3 Lowering speed, fully loaded/unloaded Full load/no load m/ s 0.36/ 0.32 5.4 Maximum climbing grade, full load/no load % 15 5.5 Service brake type Hydraulic Mechanical 5.6 Parking brake type Mechanical 6.1 Drive motor rated power S2 60 minutes kW 35 6.2 Lifting motor rated power S3 15% kW 25.4×2 6.3 Battery voltage/nominal capacity K5 Ah 6.4 Drive control type AC
