Tonghao CPD50 Electric Forklift

The Tonghao CPD50 forklift is a high-performance electric counterbalanced forklift with a rated load of 5000kg, which can easily handle the handling of various heavy-loaded materials with a maximum lift height 12′, Li-Ion Battery and Pneumatic Tires. It has a compact and sturdy structure, excellent stability and passability, and can be flexibly driven in narrow storage environments and complex factory workshops.           The efficient electric drive system achieves zero emissions and low noise operation, which meets the requirements of green environmental protection. Advanced battery management technology extends battery life and service life, meets the needs of long-term continuous work, and can effectively improve work efficiency.   In terms of configuration and operating experience, the CPD50 forklift performs excellently. The cab adopts ergonomic design, the operation interface is simple and easy to understand, the control handle is easy to operate, and the comfortable shock-absorbing seat with a wide field of vision greatly reduces the driver’s fatigue.   The vehicle’s driving speed, lifting and lowering speed can adapt to a variety of working conditions, significantly improving work efficiency. The maintenance-free AC motor and fully sealed maintenance-free battery reduce the cost and frequency of later maintenance. In addition, optional safety features such as intelligent reversing images and anti-collision warnings ensure all-round operational safety, making it widely used in material handling scenarios in warehousing and logistics, ports and terminals, manufacturing and other industries.     Technical Parameter Model CPD50 Power type Electric Operation type Saddle-type Load Q kg 5000 Load center distance C mm 600 Front overhang X mm 480 Wheelbase y mm 2045 Weight (including battery) kg 6000±200 Tire type, drive wheel/steering wheel Pneumatic tire/solid tire Drive wheel size (diameter x width) mm 250-15 Steering wheel size (diameter x width) mm 23X10-12 Drive wheel, number of steering wheels (x = drive wheel) mm 2X/2 Drive wheel track b10 mm 1140 Steering wheel track b11 mm 1080 Mast and fork tilt angle α/ β (°) 5/9 Mast height after lowering h1 mm 2310 Maximum lifting height of standard mast h3 mm 3000 Mast height when lifted to the highest level h4 mm 4250 Head guard (cockpit) height h6 mm 2260 Seat surface height h7 mm 1180 Height of towing pin center h10 mm 620 Vehicle length l1 mm 4330 Length to vertical surface of fork l2 mm 3060 Overall width b1/ b2 mm 1360 Fork size s/ e/ l mm 50X150X1220 Fork frame outer width b3 mm 1350 Ground clearance of lower end of fully loaded mast m1 mm 175 Minimum ground clearance of vehicle body m2 mm 160 Aisle width of pallet is 1200 wide x 1000 long Ast mm 4480 Aisle width of pallet is 800 wide x 1200 long Ast mm 4680 Turning radius Wa mm 2800 Travel speed, fully loaded/unloaded km/ h 12/13.5 Lifting speed, fully loaded/unloaded m/ s 0.28/0.4 Lowering speed, fully loaded/unloaded m/ s 0.45/ 0.4 Maximum climbing grade , full load/no load % 15 Service brake type Hydraulic mechanical Parking brake type Mechanical Drive motor rated power S2 60 minutes kW 18 Lifting motor rated power S3 15% kW 21 Battery voltage/nominal capacity K5 Ah Drive control type AC
